Closed-loop Motion Systems

IP53 rated
Insulation from dust, water vapor, etc.

Large Feeding Cylinder Design

Adding powder without opening the box to ensure one-time forming

Multi-scraper Adaptable

Rubber, hairbrush, high-speed steel, ceramic

Multi-filter Design

Coarse and fine filtration with high efficiency

High-efficiency Automatic Blowback System

Cartridge 1500h-long life

Wind Farm Optimization Design

Wide coverage of materials,
consistent forming quality

200°C Substrate preheating

Effective relief of forming problems such as thermal stress and thermal deformation of materials

Open-source Core Parameters

Adjustable Laser Power and Scanning Speed

Real-time monitoring

Real-time recording, output, self-diagnosis

Customer Service

Support the special service for customer

Materials

Build Size

Laser Type

Scanning System

Beam Focus System

Beam Quality

Spot Diameter

Max Scanning Speed

Layer Thickness

Platform Preheat Temperature

Powder spreading

Gas

Oxygen Content

Efficiency

Host Dimension

Installation Dimension

Power Supply

Power Consumption

Weight

Titanium Alloys, Ni-Ti Alloys, Aluminum Alloys, Superalloys, CoCr Alloys.Stainless Steel, Die Steel, Copper Alloys, High-entropy Alloys, RefractoryMetals,etc.

250mm×250mm×300mm (L×W×H)

IPG 500W×1 /×2

Scanlab High-speed Galvanometer

SILL F-theta Field Lens

M²<1.1

70~100μm (size adjustable)

7m/s

20~100μm (Layer thickness adjustable)

RT+20~200℃

One-way variable speed powder spreading

Ar/N₂

≤100ppm

30cm³/h；55cm³/h (Depends on the shape, size, material and parameters)

2300mm×1400mm×2150mm (W×D×H)

2950mm×3500mm×2600mm (W×D×H)

AC220V

8.5KW/ 10KW

1500KG/ 1650KG
