High Quality Core Components

Stable and reliable for a long time

Modules Of Design

Easy to assembly and
maintain

Recirculation Filtration Built-in System

Effective space saving

Dual Laser High-end Configuration

Two IPG 500W fibre lasers,
ultra-high printing efficiency

Mobile Forming Cylinders

Safe and efficient piece pick-up and powder removal

Dual Air Field Structure Of Wind Tunnel & Advection

Effective separation of splashes, fumes, dust, etc. for clean forming

Open-source Parameters

The parameters available for editing and directly use for customer

Real-time monitoring

Real-time recording, output, self-diagnosis

Materials

Build Size

Laser Type

Scanning System

Beam Focus System

Beam Quality

Spot Diameter

Max Scanning Speed

Layer Thickness

Platform Preheat Temperature

Powder spreading

Gas

Oxygen Content

Efficiency

Host Dimension

Installation Dimension

Power Supply

Power Consumption

Weight

Titanium Alloys, Aluminum Alloys, Superalloys, CoCr Alloys, Stainless Steel, DieSteel, Copper Alloys, etc.

325mm×325mm×420mm (L×W×H)

IPG 500W×2

Scanlab High-speed Galvanometer

SILL F-theta Field Lens

M²<1.1

70~100μm ( size adjustable )

7m/s

20~100μm (Layer thickness adjustable )

RT+20~200℃

One-way variable speed powder spreading

Ar/N₂

≤100ppm

≥45cm³/h (dependent on the shape, size, material and parameters)

2950mm×1850mm×2600mm (W×D×H)

4500mm×4000mm×3000mm (W×D×H)

AC380V

14KW

About 3000KG
