High Quality Core Components

Stable and reliable for a long time

Modules Of Design

Easy to assembly and
maintain

The Powder Feeding Structure

Accuracy of powder feeding,
replacement of different metal powders

Multi-scraper Adaptable

Rubber, hairbrush, high-speed steel, ceramic

Adjustable Parameters

Built-in parameters
adjustable according to needs

Open-source Parameters

The parameters available for editing and directly use for customer

Real-time monitoring

Real-time recording, output, self-diagnosis

Customer Service

Support the special service for customer

Materials

Build Size

Laser Type

Scanning System

Beam Focus System

Beam Quality

Spot Diameter

Max Scanning Speed

Layer Thickness

Platform Preheat Temperature

Powder Spreading

Gas

Oxygen Content

Efficiency

Host Dimension

Installation Dimension

Power Supply

Power Consumption

Weight

Titanium Alloy, Superalloy, Aluminum Alloy, Cobalt-Chromium Alloy, Stainless Steel, Die Steel, Copper Alloy, etc.

420mm×350mm×400mm（X×Y×Z）

500W×3/×4/×6/×8

High-Precision Scanning Galvanometer

F-theta Lens

M²<1.1

70~120µm

7m/s

20~100µm

RT+20℃~200℃

Single/Double Variable Speed

Ar/N₂

≤100ppm

75cm³/h;100cm³/h;150cm³/h;200cm³/h

3100mm×1400mm×2200mm（L×W×H）

5000mm×3300mm×3000mm（L×W×H）

AC380V

≤16kW; 17kW; 18kW; 20kW

Around 3000kg; 3100kg; 3200kg; 3400kg
