Large-Format Compact Build

450x400x400mm Compact footprint,maximum space efficiency,boosted productivity

Standard 6-Laser System

Ultra-high printing efficiencyFully meets diverseproduction requirements

High-Efficiency Circulating Filtration

Permanent filter cartridge High filtration efficiency,low gas consumption

60/80um Selectable Spot Size

Switchable large/small spots Balances precision and efficiency for high-quality,high-speed printing

Fully Open Core Parameters

Laser power, scanning speed, etc.Fully adjustable for flexible process customization

Full-Process Real-Time Monitoring

Real-time recording, output and self-diagnosis for end-to-end forming process

Materials

Build Size

Laser Type

Scanning System

Focusing System

Beam Quality

Beam Diameter

Maximum Scanning Speed

Layer Thickness

Platform Preheat Temperature

Recoating Mechanism

Gas Support

Working Oxygen Content

Build Efficiency

Host Dimensions

Installation Dimensions

Power Supply

Power Consumption

Equipment Weight

Titanium Alloys, Aluminum Alloys, Superalloys, CoCr Alloys, Stainless Steel, Die Steel, Copper Alloys, etc.

450mm×400mm×400mm（X×Y×Z）

500W×4/×6

High-Precision Scanning Galanometer

F-theta Field Lens

M²<1.1

60 (or 80) +3μm

7m/s

20~100μm

RT+20~200℃

Uni/Bidirectional Variable-Speed Recoating

Ar/N₂

≤100ppm

100cm³/h；150cm³/h

3450mm×1512mm×2337mm (L×W×H)

5550mm×3412mm×3200mm (L×W×H)

AC380V

18KW/ 19KW

Approx. 3600kg
