High Quality Core Components

Stable and reliable for a long time

Grand Forming size

605mm x 605mm x 650mm Large Forming Bin

Quad Laser High-end Configuration

Drastic increase in print efficiency to
meet the demands of batch production

Separate pick-up compartment built in

One-touch pick-up for safe and efficient powder removal

Dual Air Field Structure Of Wind Tunnel & Advection

Effective separation of splashes, fumes, dust, etc. for clean forming

Multi-state Sensing & Detection Configuration

All-round monitoring with high-definition recording

Open-source Parameters

The parameters available for editing and directly use for customer

Human-computer Interaction Friendly

Ergonomically designed for ease of use and smoothness

Materials

Build Size

Laser Type

Scanning System

Beam Focus System

Beam Quality

Spot Diameter

Max Scanning Speed

Layer Thickness

Platform Preheat Temperature

Powder spreading

Gas

Oxygen Content

Efficiency

Host Dimension

Installation Dimension

Power Supply

Power Consumption

Weight

Titanium Alloys, Aluminum Alloys, Superalloys, CoCr Alloys, Stainless Steel, Die Steel, Copper Alloys, etc.

605mm×605mm×650mm (L×W×H)

IPG 500W×4

Scanlab High-speed Galvanometer

SILL F-theta Field Lens

M²<1.1

70~100μm ( size adjustable )

7m/s

20~100μm (Layer thickness adjustable )

RT+20~200℃

Dual way variable speed powder spreading

Ar/N₂

≤100ppm

100cm³/h (dependent on the shape. size, material and parameters)

5100mm×4700mm×3850mm (W×D×H)

8000mm×7000mm×4500mm (W×D×H)

AC380V

16KW

About 16400KG
